SCC Series
IC Series
15-35 kV URD Cable Insulation Chamfering Tools
Easily adjustable and featuring recessed blades for greater safety.
Part No: Refer to Chart
Share this product
Downloads
- Image: Photo 1: IC 1 15-35 kV URD Cable Insulation Chamfering Tool
- Document: IC Instruction Sheet (EN)
- Catalog: Full Utility Catalog
Overview
- Chamfering tool creates a 45° bevel approximately 0.125″ (3.17 mm) in length
- Easily adjusts to fit cable diameters from 0.65″ to 1.875″ (16.51 to 47.63 mm)
- Suited for XLPE insulations
- Features safe, recessed blades to prevent injury & blade damage
Compatibility
| Cable Compatibility | Primary Distribution Underground |
|---|---|
| Cable Access | End |
| Min. Cable Outer Diameter | 0.65″ (16.51 mm) |
| Max. Cable Outer Diameter | 1.875″ (47.63 mm) |
| Insulation Materials | XLPE |
| Min. Voltage | 15 kV |
| Max. Voltage | 35 kV |
Comparison Chart
| MODEL | PART # | DIMENSIONS | WEIGHT | REPLACEMENT BLADE PART # | O.D. OVER INSULATION / SEMI-CON | CHAMFER ANGLE | SHAVE LENGTH |
|---|---|---|---|---|---|---|---|
| IC 1 | 34760
Quickship Available: Many of our products can ship out to your local authorized distributor within 48 hours. If you see a QuickShip icon next to an item and you need it FAST, let your distributor know and we will expedite it.
|
3.5″ x 3.5″ (88.9 x 88.9 mm) | 10 oz (284 g) | 34766 | 0.65″ - 1.26″ (16.51 - 32.0 mm) | 45° | 0.125″ (3.17 mm) Chamfer |
| IC 2 | 34825 | 4.188″ x 4.188″ (106.4 x 106.4 mm) | 12.5 oz (355 g) | 34766 | 1.25″ - 1.875″ (31.75 - 47.63 mm) | 45° | 0.125″ (3.17 mm) Chamfer |
