US15 PRO MAX

Large Format Slitting Tool

Heavier duty slitting tool designed to assist in the removal of outer sheathing and primary insulation on low and medium voltage power cables.

See all distributors

Part No: Refer to Chart

Share this product

Downloads

Overview

Introducing Ripley’s US15 PRO MAX Large Format Slitting Tool, capable of performing slit, ring, and spiral cuts on cable diameters from 38 to 80 mm. Equipped with a high-grade steel blade, the versatile tool provides fast, safe, and precise jacket removal from both hard and soft insulated cables without damaging the underlying layers.

  • Equipped with safe, recessed blade to prevent potential injury & blade damage
  • Compatible with various insulated materials such as PE, XLPE, PVC, EPR, silicon rubber, EPDM and TGGT
  • Easily adjust the blade position to perform ring, spiral & longitudinal cuts
  • Quickly adjusts to suit hard & soft insulated cables with 1.50” to 3.15” (38 mm – 80 mm) diameter
  • Blade depth knob adjusts up to 0.216″ (5.5 mm) in increments of 0.002″ (0.05 mm) & features a convenient inch or metric scale for guaranteed precision
  • Replaceable, machined & ground tool steel blade
  • Reinforced diameter adjustment jaw is durable & travels on a threaded rod to provide precise stability between the blade & jacket

Compatibility

Cable Access Mid-Span, End
Min. Cable Outer Diameter 1.50″ (38 mm)
Max. Cable Outer Diameter 3.15” (80 mm)
Jacket Materials PE, XLPE, PVC, EPR, Silicon Rubber, EPDM, TGGT, Sealpic®
Adjustable Blade Depth 0.216″ (5.5 mm)

Specifications

Material Impact-Resistant Polymer
Handles Ergonomic
Length 5.125″ (130 mm)
Weight 8.82 oz (250 g)
Replacement Blade Part # US15-7501
Cutting Type Radial, Spiral, Longitudinal

Comparison Chart

MODEL PART # SCALE SCALE INCREMENTS
US15 PRO MAX Large Slitting Tool (Metric Scale) US15-7110 Metric 0.05 mm
US15 PRO MAX Large Slitting Tool (Inch Scale) US15-7111 Inch 0.002″
